Glass Fiber Geogrid

Attributes
Color: Black
Application: Road Construction
Width: 1-6m
Mesh Size: 12-50mm

Fiberglass geogrid is a new kind of favorable earthwork base material to strength the road surface and road bed, which composed of fiberglass filaments coated with an inorganic sizing agent. These fiberglass products possess the advantage of high tensile strength in the warpand weft directions, low elongation, excellent temperature range, and good anti-aging and alkali-resistance. Fiberglass geogrid is extensively used for the reinforcement of asphalt pavement, concrete pavement and roadbeds. Compared to traditional materials, fiberglassgrid can reduce construction cost, extend road serviceand prevent deflection crack. Fiberglass geogrid can also be used to reinforce roadbed in soft soil for railways, airfields imigation channels,and water dams.

Application:

l  It reinforces old asphalt concrete road surface and asphalt surface layer, and prevents damage.

l  It is used for rebuilding cement concrete road surface into composite road surface and restraining reflection caused by block contraction.

l  It is used in road expansion and improvement project and crack caused by old and new combination position and uneven sedimentation.

l  It is used in soft soil base reinforcement treatment, is favorable for soft soil water separation and concretion, restrains sedimentation effectively, distributes stress uniformly and improve overall strength of road base.

l  It is used for preventing contraction crack caused by new road seni-rigid base layer, and reinforcing and preventing road surface crack caused by foundation crack reflection.

Features:

l  High tensile strength in the warp and weft directions

l  Low elongation

l  Excellent temperature range

l  Good anti-aging and alkali-resistance

l  Compared to the traditional use of fiberglass geogrid, it can reduce the construction cost, extend road service life and prevent deflection cracks

Specification:

Type

Breaking Strength(KN/m)

Elongation at break(%)

Mesh Size

(mm)

Width

(m)

Wrap

Weft

Wrap

Weft

GG2525

≥25

≥25

≤3

≤4

12-50

1-6

GG3030

≥30

≥30

≤3

≤4

12-50

1-6

GG4040

≥40

≥40

≤3

≤4

12-50

1-6

GG5050

≥50

≥50

≤3

≤4

12-50

1-6

GG8080

≥80

≥80

≤3

≤4

12-50

1-6

*Specific products could be made according to customers’requirements.
