Quartz Fiber Wet-laid Mat

Attributes
Thickness: 0.03-0.12mm
Width: 50-2500mm
Comment: Hand lay up/Filament Winding/Pultrusion

Quartz Fiber Wet-laid Mat is made of randomly distributed wet quartz fiber chopped strands held together by designed binders into mat. Except same properties as glass fiber wet-laid mat, quartz fiber wet-laid mat also have the typical the quartz fiber properties, such as heat insulation, wave transmissin, etc.

Application:

Mainly used in composite for surface moulding and polishing

Specification:

Hitex

Quartz Fiber Wet-laid Mat

Thickness

(mm)

Width

(mm)

H

QMW

0.03-0.12

50-2500


Item No.

Areal Weight

(g/m2)

Thickness

(mm)

Tensile Strength

(N/50mm)

Wetting Out

(S)

Water Content

(%)

LOL

(%)

Comment

QMWH30

30

0.03

≥20

≤10

≤0.50

≤10

Hand lay up

QMWH50

50

0.05

≥30

≤20



QMWF30

30

0.03

≥25

≤10



Filament Winding

QMWF50

50

0.05

≥40

≤16



QMWP90

90

0.09

≥100

/



Pultrusion

QMWP105

105

0.11

≥110

/



*Specific products could be made according to customers’requirements.
